Screen Railing Systems
Ultralox’s screen railing system provides a clean, durable way to enclose outdoor spaces while maintaining airflow and visibility. Built from powder-coated aluminum with integrated screen channels and hidden fasteners, it installs easily on porches, patios, and balconies—without the rot, warping, or upkeep of wood or vinyl alternatives.
Overview
Clear Views, Confident Design
- All-Aluminum Construction: Rust-free, powder-coated, and engineered to last in any climate.
- Integrated Screen Channel: Accepts standard screen spline for fast field screen installation.
- Clean, Modern Profiles: Hidden fasteners and bracketless design create a smooth finish.
- Flexible Configurations: Designed for porches, balconies, and open patio conversions.
- Code Ready: ICC-ES AC273–compliant when used as a guardrail system.
Details & Specifications
Material & Finish
- 6000-series extruded aluminum
- AAMA 2604 powder-coated finish
- Color options: Black, White, Bronze
- Components ship fully painted and pre-cut to standard lengths
System Components
- Screen panels
- Top and bottom rails
- Integrated spline channels (no exposed screen framing)
- Compatible 2in and 3in posts
Panel Dimensions
- Widths: 6ft and 8ft panels
- Heights: 36in (residential) and 42in (commercial)
- Optional bottom rail support leg for longer spans
Screen Details
- Integrated spline groove accepts standard screening
- Compatible with fiberglass, aluminum, or specialty screen material (not provided)
- Screen installation is field-applied after frame is installed
Installation
- Pre-assembled panels with hidden fasteners
- Drop-in rail covers conceal all brackets
- Step-by-step install instructions and video support
Performance & Compliance
- ICC-ES AC273 certified for guardrail use
- Meets residential and commercial safety code requirements
Warranty
- 20-Year limited finish and structural warranty
- 10-Year coastal finish warranty with approved primer
Resources
General Resources
Commercial Resources
Customize Your Railing
Colors
Black
White
Bronze
Get Started Today
